Name: Mono Solar Panel 120W with 50A contller with mount
Brand: The Shopsite
Price: 184.99 NZD
Availability: OutOfStock

This 120W monocrystalline solar panel is engineered with high-efficiency A-grade Trinasolar cells, delivering dependable power generation for residential, off-grid, RV, and remote applications. The panel arrives ready to install, complete with a 50A charge controller, mounting brackets, a screw kit, and 900mm MC4 cables, making it a comprehensive solar solution straight out of the box. The IP65-rated junction box with a built-in bypass diode ensures reliable operation even when partial shading occurs, while the robust aluminium-framed construction handles extreme weather with ease.

This solar panel is well suited to a wide range of applications, including residential solar energy systems, RVs and caravans, mobile homes, remote power generation, and off-grid solar setups. Its wide operating temperature range and high load ratings make it a practical choice for New Zealand's diverse conditions, from coastal environments to alpine locations.

Specifications

Cell Type	Mono-crystalline silicon
Output Power	120W
Operating Voltage	18V
Open Circuit Voltage (Voc)	21.6V
Short Circuit Current (Isc)	7.19A
Max Power Current (Imp)	6.66A
Cell Efficiency	20.50%
Module Efficiency (STC)	18.47%
Power Tolerance	±3%
Normal Operating Cell Temperature (NOCT)	47°C ± 2°C
Operating Temperature Range	-40°C to +85°C
Temperature Coefficient of Pmax	-0.435%/°C
Temperature Coefficient of Voc	-0.35%/°C
Temperature Coefficient of Isc	0.043%/°C
Wind Load	2400 Pascal
Snow Load	5400 Pascal
Dimensions	1080 x 700 x 30 mm
Weight	7.2 kg
Junction Box Rating	IP65
Cable Length	900mm with MC4 connectors
Application Class	Class A
Fire Rating	Class C
Warranty	10 Years

What's Included

Solar Panel	1 x 120W monocrystalline solar panel
Charge Controller	1 x 50A solar charge controller
Mounting Brackets	4 x brackets
Screw Kit	1 x screw kit
Cables	900mm MC4 connector cables
