Introducing centrifugal water pump – Stainless Steel Jet Pump for Large Homes with 1 HP power. This pump is designed to provide excellent water pressure for medium-sized single or double-level homes, supporting up to 5 taps running simultaneously. It is equipped with an electronic automatic constant pressure control system, ensuring a consistent pressure at a steady flow rate. The pump starts automatically when a tap is turned on and stops automatically when the last tap is turned off. It operates continuously from low flow to full flow, delivering reliable performance.
Specifications:
- Power: 750W – 1 Horsepower
- Single phase with standard NZ 3 pin plug
- Maximum Flow rate: 70 Liters per minute
- Maximum Pressure: 62 psi
- Maximum suction lift: 8 meters
- Maximum discharge head: 43 meters
- Weight: 10 kg
- Inlet/Outlet sizes: 1 inch BSP (equivalent to 25mm)
- Built-in thermal overload protection
- Insulation class B
- IP55 Protection
- Rated for continuous duty
- Liquid temperature range: 5 – 60 degrees Celsius
- Maximum operating pressure: 6 bar
- Length: 370 mm
- Height: 360 mm
- Width: 200 mm
Common Applications:
- Water supply for medium and large-sized homes
- General water transfer systems
- Domestic household pumps
Key Features:
- Fitted with an electronic automatic constant pressure control system
- Self-priming capability
- Starts automatically when the tap is turned on (at a pressure drop to 2.2 bar)
- Operates consistently from low flow to full flow
- Stops automatically when the last tap is turned off
- Run Dry Protection feature
- Corrosion-resistant stainless steel construction
- Stainless steel pump housing
- Stainless steel motor shaft
- Built-in thermal overload protection
- The BJZ100E Stainless Steel Jet Pump offers reliable water supply and excellent performance for larger homes. With its constant pressure control system and durable stainless steel construction, this pump ensures consistent water flow and longevity.
Pacakaging Contains:
- 1 x water Pump
