Solar Panel Mono Crystalline 100W with controller and mount

100W Mono-crystalline Solar Panel

Enhance your renewable energy setup with the high-efficiency 100W Mono-crystalline Solar Panel, featuring durable construction and reliable performance.

Features:

• High Efficiency: Manufactured with A-grade Mono-crystalline Trinasolar® cells for maximum solar production.
• Durable Construction: 3.2mm safety/tempered glass with low-iron content for enhanced light absorption. Corrosion-resistant anodized aluminum frame for easy mounting.
• Weather Protection: IP65-rated junction box with weather-tight seal and built-in bypass diode for added protection during partial shading.
• Specifications:
  • Output Power: 100W
  • Operating Voltage: 18V
  • Conversion Efficiency: 18%
  • Working Current: 5.5A
  • Open Circuit Voltage: 21.6V
  • Power Tolerance: ±3%
  • Cell Efficiency: 20.50%
  • Module Efficiency (STC): 18.47%
  • Operating Temperature Range: -40°C to +85°C
  • Size: 1200 x 550 x 30mm
  • Weight: 7kg
• Temperature Coefficients:
  • Pmax: -0.435%/°C
  • Voc: -0.35%/°C
  • Isc: 0.043%/°C
  • Normal Operating Cell Temperature: 47°C ± 2°C
• Wind Load: 2400 Pascal
• Snow Load: 5400 Pascal
• Warranty: 10 Years
• Application Class: Class A
• Fire Rating: Class C

Package Includes:

• 1 x High-Efficiency 100W Mono-crystalline Solar Panel
• 1 x 30A 12V/24V Auto Switch Charge Controller

We also offer a variety of other solar panel sizes ranging from 20W to 320W. Check our store for more options!
