Solar Panel 150W

150W Poly-Crystalline Solar Panel – High-Efficiency, Lightweight Design

Elevate your energy solutions with our 150W Poly-Crystalline Solar Panel. Designed for optimal performance and versatility, this high-efficiency solar panel is perfect for a range of applications including boats, caravans, and home installations. Its lightweight design and robust construction ensure reliability and durability, making it a great addition to your solar power system.

Product Features:

• High Efficiency: 150W maximum power output, providing reliable energy generation.
• Robust Construction: Features a rigid anodised aluminium alloy frame and toughened glass for enhanced durability.
• Compact and Lightweight: Measuring 1480 x 680 x 35mm and weighing just 9.85kg, it’s easy to install and transport.
• High Performance:
  • Maximum Power Voltage (VMP): 18.0V
  • Maximum Power Current (IMP): 8.33A
  • Open Circuit Voltage (VOC): 21.60V
  • Short Circuit Current (ISC): 9.17A
• Power Tolerance: ±3% ensuring consistent and reliable power output.
• Maximum System Voltage: DC1000V, suitable for various solar applications.

Specifications:

• Battery Voltage Compatibility: 12V/24V Auto
• Charging Current: 30A
• Discharging Current: 30A
• Max Solar Input: 50V (for 24V battery), 25V (for 12V battery)
• Equalization Voltages:
  • Sealed: 14.4V
  • Gel: 14.2V
  • Flood: 14.6V
• Float Charge Voltage: 13.7V (default, adjustable)
• Discharge Stop Voltage: 10.7V (default, adjustable)
• Discharge Reconnect Voltage: 12.6V (default, adjustable)
• Operating Temperature: -35°C to +60°C

Applications:

• Power Stations
• Power Generation Systems
• Street Lights
• Garden Lights
• Solar Cars
• And many other applications

Package Includes:

• 1 x High-Efficiency 150W Poly-Crystalline Solar Panel
• Note: Wiring as per photo is not included. MC4 cables and other components are available separately.
