EPEVER Tracer MPPT Solar Charger 20A

EPEVER Tracer MPPT Solar Charger 20A

The EPEVER Tracer MPPT Solar Charger 20A is an upgraded charge controller featuring Solar Charge Controller  advanced MPPT technology and multiple load work modes. It is designed with a Negative Ground Design and is suitable for various battery types including GEL, Sealed, Flooded, Solar Charge Controller  and Lithium Battery.

Features:

• Advanced MPPT technology with Solar Charge Controller  efficiency no less than 99.5%
• Ultra-fast tracking speed and excellent tracking efficiency
• Accurately recognizing and tracking multiple power points
• Multi-function LCD displays system information intuitively
• Solar Charge Controller  User programmable for battery types, load control, etc.
• 4-Stage MPPT charge with multiple load work modes
• Common positive grounding design
• RS485 port with industrial standard MODBUS open architecture Solar Charge Controller

Specifications:

• Model: Tracer2210AN MPPT charge controller
• Rated charge current: 20A
• Rated discharge current: 20A
• System voltage: 12/24V DC Auto
• Solar Charge Controller  Max. PV input power: 260W/12V, 520W/24V
• Grounding: Common Negative Ground
• Battery voltage range: 8-32V
• Max. PV open circuit voltage: 100V, 92V (25°C) Solar Charge Controller
• MPP Voltage range: BAT Voltage+2V-72V
• Self-consumption: 12mA
• Discharge circuit voltage drop: 0.23V
• Solar Charge Controller  Temperature compensate coefficient: -3mV/°C/2V (Default)
• RS485 interface: 5VDC/100mA
• LCD backlight time: 60S (Default)
• Working environment temperature: -25°C to +50°C (100% input and output)
• Storage temperature range: -20°C to +70°C
• Relative humidity: 95%, N.C.
