Mono Solar Panel 150W

150W Monocrystalline Solar Panel

Product Overview:

The 150W Monocrystalline Solar Panel is a high-efficiency solar energy solution, designed with A-grade monocrystalline Trinasolar cells for superior performance. It is built for durability and reliability, featuring an IP65-rated junction box that protects against weather conditions and includes a built-in bypass diode for enhanced safety during partial shading. The solar panel comes with 900mm pre-installed cables and MC4 connectors, making it easy to integrate into your existing solar system.

Key Features:

• High-Efficiency Cells: Manufactured with A-grade monocrystalline Trinasolar cells, ensuring high performance with 20.50% cell efficiency and 18.47% module efficiency.
• Weatherproof Design: The Solar Panel 150W is built with IP65 waterproof protection and a 3.2mm tempered glass front, making it suitable for outdoor use in various weather conditions.
• Durable Frame: Solar Panel 150W is constructed with a heavy-duty aluminum frame to withstand wind loads of 2400 Pascal and snow loads of 5400 Pascal, ensuring longevity and stability.
• Safety and Efficiency: The built-in bypass diode prevents power loss in shaded areas, and the MC4 connectors make setup and integration seamless.

Specifications:

• Power Output: 150W
• Voltage Range: 12V to 18V
• Open Circuit Voltage (Voc): 22.65V
• Short Circuit Current (Isc): 9.06A
• Rated Current (Imp): 8.36A
• Number of Cells: 36 cells (156 x 156 mm)
• Dimensions: 1480 x 680 x 40 mm
• Weight: 12 kg
• Temperature Coefficient of Pmax: -0.435%/°C
• Temperature Coefficient of Voc: -0.35%/°C
• Temperature Coefficient of Isc: 0.043%/°C
• Normal Operating Cell Temperature (NOCT): 47°C ± 2°C
• Maximum System Voltage: 1000V
• Operating Temperature Range: -40°C to +85°C
• Wind Load: 2400 Pascal
• Snow Load: 5400 Pascal
• Warranty: 10 Years

Applications:

• Ideal for motorhomes, boats, caravans, and off-grid solar setups.
• Suitable for use in outdoor environments where durability and reliability are required.

Available Sizes: We also offer solar panels in other sizes including 20W, 30W, 50W, 100W, 200W, 260W, 280W, and 320W. Please check our store for more options.

The 150W Monocrystalline Solar Panel provides a reliable, efficient, and durable solution for all your solar energy needs, backed by a 10-year warranty for peace of mind.
