Mono Solar Panel 120W

120W Monocrystalline Solar Panel

120W Monocrystalline Solar Panel

Upgrade your energy solutions with our high-efficiency 120W Monocrystalline Solar Panel. Manufactured with A-grade Mono-crystalline Trinasolar® cells, this panel ensures optimal performance and durability. Designed for a wide range of applications, it comes with a weather-tight junction box and standard MC4 connectors for ease of use in any environment.

Features:

• High-efficiency A-grade Mono-crystalline Trinasolar® cells.
• Weather-tight junction box with an IP65 rating.
• Built-in bypass diode for added protection during partial shading.
• Supplied with 900mm cable for positive/negative connections.
• Standard MC4 connectors crimped onto each cable for easy installation.

Specifications:

• Output Power: 120W
• Operating Voltage: 18V
• Short Circuit Current: 7.19A
• Max Power Current: 6.66A
• Open Circuit Voltage: 21.6V
• Dimensions: 1480mm x 540mm x 30mm
• Weight: 7.2 kg
• Power Tolerance: ±3%
• Cell Efficiency: 20.50%
• Module Efficiency (STC): 18.47%
• Operating Temperature Range: -40°C to +85°C
• Normal Operating Cell Temperature: 47°C ± 2°C
• Wind Load: 2400 Pascal
• Snow Load: 5400 Pascal
• Application Class: Class A
• Fire Rating: Class C

Temperature Coefficients:

• Temperature Coefficient of Pmax: -0.435%/°C
• Temperature Coefficient of Voc: -0.35%/°C
• Temperature Coefficient of Isc: 0.043%/°C

Packaging Includes:

• 1 x 120W Mono Solar Panel

We also sell 20W, 30W, 50W, 100W, 150W, 200W, 260W, 280W, and 320W solar panels. Please check our store for more options.
